86
5.3.4
5.3.5
5.3.6
ChipProg Device Programmers
IMPORTANT! After programming of all the memory layers ( Code, Data , User , etc.) you need to
program the options preset in the Device and Algorithm Parameters Editor window , if they have
been modified . Go down to the Device parameters & ID line, expand it if collapsed, select the
Program function and double click it. Device and Algorithm Parameters window
6. Some microcontrollers can be protected against unauthorized reading of the written code by setting
a set of Lock bits . Go down to the Lock bits line, expand it if collapsed and double click the lock
bit# lines one by one. You can optionally lock only certain parts of the device memory. Continue
until every lock bit is set.
7. After every operation above make sure that you watch the Ok [xxxxx... Ok] message in the
Operation Progress box of the Program Manager tab . In case you get an error message stop the
programming and troubleshoot the issue.
How to read a device
There are several ways for reading the device content to an active buffer:
a) Click the Read button on the main toolbar or
b) Double click on the Read function line in the Function list of the window or
c) Select the Read function line in the Function list of the Program Manager window and click
the Execute button or
d) Select the Main menu > Commands and click on the Read line
then wait for the message Reading … OK in the Program Manager window or for the warning
message if the device could not be read out.
How to verify programming
There are several ways for checking if the device was programmed correctly:
a) Click the Verify button on the main toolbar or
b) Double click on the Verify function line in the Function list of the Program Manager window
or
c) Select the Verify function line in the Function list of the Program Manager window and click
the Execute button or
d) Select the Main menu > Commands and click on the Verify line
then wait after that which Verifying … OK Program Manager window or for the warning message
if the device failed during the verification process.
How to save data on a disc
1. After you have read out the device content into the Buffer or a specified Buffer layer you may need
to save the read data on a PC disc . To save the data:
a) Click the Save button on the local toolbar of the Buffer window or
b) Select the Main menu > File > Save
2. In the pop-up dialog specify the destination file name, format, start and end addresses of the source
(the buffer), and the source sub-level, and click OK.
? 2010 Phyton, Inc. Microsystems and Development Tools
